From Raw Cavity to Showroom-Ready in One Seamless Process.

The conveyor and tooling are unsung heroes of the oven enamel production line. An oven cavity is a large, awkward, three-dimensional part that must be held securely and oriented correctly throughout the entire process. The custom tooling designed by TIMS COATING must hold the cavity firmly without leaving significant "witness marks" on the finished product. It must also orient the cavity to allow for proper drainage in the pretreatment section and optimal access for the robotic sprayers. Finally, the tooling itself must be made of high-temperature alloys to withstand thousands of trips through the 850°C furnace. The expert design of this tooling is a critical part of a successful oven enamel production line.

The process performed on an oven enamel production line is a precise, multi-stage sequence. It begins with deep-drawing the steel sheet into the box shape of an oven cavity. This cavity is then loaded onto the line and enters a 1. Pretreatment section to be thoroughly cleaned and etched. 2. Ground Coat Application: A cobalt-rich base coat is applied, typically via robotic spraying. 3. Firing: The cavity is fired in a furnace at ~850°C to fuse the ground coat to the steel. 4. Cover Coat Application: After cooling, the final colored (e.g., blue or black) cover coat is applied. 5. Second Firing: The cavity is fired again to fuse the cover coat, creating the final smooth, durable surface. This complete process is automated on a TIMS COATING oven enamel production line.

A ground coat is the foundational first layer applied in a high-quality oven enamel production line. It is typically a dark, cobalt-rich enamel. Its purpose is not cosmetic; it is purely functional. The cobalt in the formulation interacts with the steel substrate at high temperatures to create a powerful chemical and mechanical bond that is far stronger than a standard cover coat could achieve on its own. It also provides a flexible interface layer that helps absorb the stress between the expanding and contracting steel and the glass top coat. An oven enamel production line that skips the ground coat stage is producing a significantly inferior product that is much more likely to fail from chipping or thermal shock.

A pyrolytic or "self-cleaning" oven requires an extremely durable enamel that can withstand temperatures of 500°C (930°F) to burn off food soils. A standard enamel would fail under these conditions. The difference is created on the oven enamel production line. Both types use a similar process, but the pyrolytic version uses a specially formulated enamel frit with a higher temperature resistance. Furthermore, the quality control on the line must be even more stringent, as any microscopic flaw in the finish could become a failure point during the intense self-cleaning cycle. A TIMS COATING oven enamel production line has the process control required to produce high-quality pyrolytic finishes reliably.
